In continuous composites manufacturing, both hot calendering and double belt press (DBP) lamination apply heat and pressure to produce a continuous laminate or sheet, providing high quality results in large volumes.
The key difference lies in how that heat and pressure are delivered, and how much control the process provides over time.
Hot Calendering x Double Belt Press Laminating:
How to determine which one is right for your process?
In simple terms, hot calendering is best suited to fast, efficient shaping and thickness control, while a double belt press is better suited to continuous laminates that require controlled consolidation and cooling.
Hot Calendering: Quicker Processing
Hot calendering is well suited to processes where the main objective is to reduce thickness, laminate layers, improve surface finish, or compact a structure quickly.
Because the material passes through the nip between heated rolls, the process is efficient and can operate at high speed. This makes calendering attractive for relatively simple laminates, film-based structures, and products that do not require a long period under pressure.
Double Belt Press: Longer and Controlled Processing
A double belt press is more suitable when the laminate requires a longer, more controlled process path along the production line. It can also be better suited to thicker laminates and more demanding structures, where uneven pressure or incomplete bonding can make hot calendering less effective.
In double belt press systems, the material travels between two moving belts through successive heating and cooling zones, allowing deeper consolidation, more uniform pressure distribution, and a longer processing window.
Consistent laminate quality depends on how well the polymer melts, flows, bonds with the reinforcement, and then solidifies. The longer dwell time under pressure can reduce voids, improve interlayer bonding, and create a more uniform structure.
